Air transit route

Utilisation
Dedicated to delimitation of Air transit route

Colours
• The markers are available in colours complying with ICAO recommendations : yellow / green / yellow.
• Retro-reflective height: 240 m

Installation
Mounting directly in the ground or with a fixation support (on request).

Advantages
• 360° Horizontal visibility by day or night owing to its cylindrical shape.
• Retro-reflective film - High Intensity of various dimensions and colours in compliance with ICAO - Annex 14, Appendix 1.3.
• Marker in coloured plastic material (PE/HD) resisting to UV radiationand non corrosive. Frangibility on impact. Excellent resistance to air blasts. No electrical connection. No maintenance.

Compliance
ICAO : Complies with Annex 14, Volume II, §5 .

Technical data
Total Height : 430 mm
Visible Height : 240 mm
Visible Diameter : 75 mm
