Helipad Lighting

Research, studies and design
• The electroluminescent panel has been developed specifically for helicopter use.It is designed to delineate the perimeter of helipads for night flying.
• During descent, the relative size of the EP55 panel will increase so that pilots are always able to judge their height above the helipad.
• It can be safely landed on by most types of helicopter.
• Robust, durable and corrosion protected, the EP55 can operate undamaged when subjected to dust, rain, snow or salt air driven by high winds.

Structure
• Thin anti corrosion aluminium profile.
• Protection with yellow polyester paint .
• Front face polymetacrylate 9mm, UV and chemical resistant.
• Other metallic parts in stainless

Technical data
• Power: 4 W
• Brightness: Compliant with ICAO(Annex 14, Vol II 5.3.7)
• Light output and colour: > 55 Cd/sq mYellow or others
• Strip lighting surface: 740 sq cm
• Life > 80 000 hrs • Overall dimensions : 1460mm x 180mm x 20mm
• Weight: 7.2 kg

Compliance
ICAO-Annex 14,Volume II, 2nd Edition (5.3.7).

Inverter Power Supply
• Mains powered, self-contained AC to DC inverter providing a DC output.Force ventilated for temperature control.
• Input: 230 VAC 50Hz (others on request). Output: 30 VDC
• Protection: Over current on input and output.
• Rating: Suitable to the number of panels in the system – Maxi 250 W.

Installation
The system comprises a variable number of panels, junction boxes, cable and inverter.

Panels may be fixed to a variety of surfaces including concrete, tarmac, composite or metallic structure and grass.

Advantage
• Very low consumption - 4 Watts
• No « black hole » effect, no dazzling of pilots
• Resistant to vibrations. No fragile glassware.
• Very low protrusion height • Life > 80 000 hrs

Applications
Corporate and Private Uses (Civil and Military)
• Hospitals
• Navy
• Offshore Oil and Gas Rigs
• High Rise Buildings
• Offshore Oil and Gas Rigs
• High Rise Buildings
